Classic surface-mounted switch in black porcelain without a knob in a design that was common in Europe during the first half of the 20th century.
This switch has a so-called staircase function, which means that it can be used as a regular switch to turn a light source on and off.
It can also be used in rooms, corridors or staircases to switch on a light source at one end of the room and off at the other. If a staircase connection is required, two switches with staircase function are needed.
If a light source is also controlled by a third switch, this switch must have a cross function. In the side of the base there is an opening for cable exit for surface-mounted electrical wiring, but it can also be mounted for recessed wall box in combination with any of Fontini’s base plates.
For surface mounting on wood paneling or other flammable material, an insulating plastic base plate can be used as additional fire protection.
Combine the switch with the optional knob sold separately. See related products.
Specifications
| Weight | 0.2 kg |
|---|---|
| Function | step switch |
| Material | fully cast in porcelain |
| Color | White |
| Screw included | yes |
| Note! | knobs sold separately |
| CE marked | yes |
| Expanding | 56 mm incl. knob |
| Bottom diameter | 65 mm |
| Technical specification | 10AX – 250V~ |
| IP-class | IP20 |
| Mounting | Outside |
Documents and instructions
No documents
